| Platform | |
| Form Factor | CASwell NIC Module |
| LAN Controller | 1 x Intel E810 CAM1 or CAM2 |
| Ethernet Port | 1 x QSFP28 100 GbE Port(s) on board Up to 1 x Ethernet Port(s) with maximum 100GbE bandwidth |
| Bus Type | Proprietary PCIe Gen4 x8 |
| Dimension (WxDxH) | 75mm x 185mm x 16mm (3" x 7.4" x 0.64") |
| Operation & Certifications | |
| Operating Environment | Temperature: 0 - 45°C (32 - 113°F) Humidity: 20 - 90% RH |
| Storage Environment | Temperature: 0 - 70°C (32 - 158°F) Humidity: 5 - 95% RH |
| OS Support | Linux / Windows |
NIN-88010
Single Port QSFP28 Fiber Ethernet PCI-E and Network Adapter100 GbE Proprietary Adapters
- Intel E810 CAM1 or CAM2 LAN Controller
- 1 x QSFP28 100 GbE Ports
- Proprietary PCIe Gen4 x8
